Co Axial Cable PVC Compound

Get a Price/Quote

MOQ : 10 Pieces

Co Axial Cable PVC Compound Specification

HS Code
390410

Temperature
-20C to +70C

Processing
Extrusion/Molding

Material
PVC

Harness
Flexible

CAS No
9002-86-2

Smell
Odorless

Type
Co Axial Cable PVC Compound

Appearance
Smooth, uniform granules

Color
Brown

Shape
Other

Relative Density
1.40 - 1.50 g/cm3

Shore Hardness
98%

Tensile Strength(Mpa)
12 - 15 MPa

Elongation(%)
180%

Heat Stability
180C

Weather Resistance
Excellent

Compatibility
Suitable for RG, RF and CCTV cables

Flame Retardancy
Self-extinguishing

Volume Resistivity
> 1 x 10^13 cm

Dielectric Strength
15 kV/mm

Packaging
25 kg bags

Water Absorption
<0.2%

UV Resistance
Good

Storage Condition
Cool, dry place, away from direct sunlight

Co Axial Cable PVC Compound Trade Information

Minimum Order Quantity
10 Pieces

Supply Ability
500 Pieces Per Week

Delivery Time
2-3 Days

Main Domestic Market
All India

About Co Axial Cable PVC Compound

We are well known in the global market for supplying superior quality Co axial cable PVC Compound. It is processed under the supervision of highly qualified team of skilled workforce using premium quality compounds. The product finds its usage in manufacturing of co axial cables. We supply this Co axial cable PVC Compound to clients after proper checking on the predefined quality standards of the industry.

Features:

No toxic gas emission
High temperature resistance
Low smoke emission

TECHNICAL DATA SHEET

Polyvinyl Chloride Compound
CW 34 is an extra soft grade designed for use in sheathing of Co-axial TV Cables.

PROPERTIES	STANDARD	UNIT	TYPICAL VALUE
PHYSICAL
Appearance			Granular
Specific Gravity	ASTM D 792		1.45 Â± 0.03
MECHANICAL
Hardness	ASTM D 2240	Shore A	82 Â± 3
Tensile Strength (min.)	IS 10810	MPa	15
Elongation at Break (min.)	IS 10810	%	250
Properties after ageing at 80^oC for 7 days
Variation in Tensile Strength	IS 10810	%	Â± 20
Variation in Elongation at Break	IS 10810	%	Â± 20
Loss of Mass	IS 10810	mg/cm²	2 (max.)
THERMAL
Thermal Stability @ 200^oC (min.)	IS 5831	Minutes	50
PROCESSING INFORMATION
Temperature Range		^oC	155â€“185
